Product Details
APPLICATIONS
- Sanitary sewage pumping stations
- Pressure sewage systems
- Commercial and residential sewage removal
SPECIFICATIONS
Pump:
- Discharge: 1-1/4” BSPT horizontal
- Seals – Silicon Carbide/Carbon, Buna-N elastomers
- Construction – motor housing, cover, adapter and pump housing cast iron ASTMA A-48, corrosion-resistant, powder coated epoxy finish
- Attaching hardware – 304 stainless steel
- Square ring and gasket – Viton
- Stainless steel cutter and plate hardened to Rockwell C 55-60
- Pressure relief valve
- Stainless steel legs provide for free-standing installation
- Stainless steel helix hydraulic rotor
- Buna-N hydraulic stator
Motor:
- Permanent split capacitor (PSC) motor
- Stator – Class B insulation and lead wires, Nema B design
- Integral thermal overload protection with automatic reset
- Housing – Finned cast iron, oil-filled
- 416 stainless steel motor shaft
- Upper and lower ball bearings – dual, high carbon chromium steel
- 6 m (20′) power cord
Note:
Product information presented here reflects conditions at time of publication. Consult factory regarding discrepancies or inconsistencies.
